Full Spectrum Mirrorless Canon EOS R Digital Camera Body - Used
Delivery: Full Spectrum DSLR and Full Spectrum Mirrorless Modified Cameras are acquired, modified and sold on-demand and have an estimated order fulfillment time of 10 business days (about 2 weeks) before shipping. All modified DSLR or Mirrorless digital cameras sales are final. No returns. 1 year warranty (warranty coverage details on product description).
Features
- 30.3MP Full Frame CMOS Sensor with 5.36 µm Square pixel size
- Unlocked sensitivity to ultraviolet light wavelengths below 400nm
- Unlocked sensitivity to infrared light wavelengths above 700nm
- Up to 4X Hydrogen Alpha transmission increase at 656nm wavelength
- Up to 6X Sulfur II transmission increase at 671.7nm and 673nm wavelengths
- Astronomik clear glass with Anti-Reflective coatings installed in front of the sensor**
- No Low Pass Anti-Aliasing Filter (Camera sensor performs at native maximum sharpness without self-cleaning function)
- ISO Range: 100 to 40000 (Extended ISO: 102400)
- Built-in 3.69m-Dot OLED Electronic Viewfinder
- 3.15" 2.1m-Dot Vari-Angle Touchscreen LCD
- Built-in WIFI (Great for Electronically-Assisted Astronomy with Phones and Tablets)
- DIGIC 8 Image Processor
- UHD 4K 24fps / HD 1080p 60fps / HD 720p 120fps Video Recording
- Improved Dual Pixel CMOS AF
- Magnesium alloy body
- Compatible with N.I.N.A., ZWO ASIAIR Plus, BackyardEOS and Astrophotography Tool
- 1 Year Warranty*
- Description
- Specifications
- What's included
- Reviews
Overview
Compact, Pro-level Mirrorless digital camera professionally converted for unlocked Full Spectrum sensitivity to ultraviolet and infrared light and increased 4X H-alpha nebulae emission sensitivity and 6X Sulfur II nebulae emission sensitivity.
Condition: Used excellent condition body with minor signs of cosmetic wear.
Astronomik MC Clear Glass
Both Low Pass Filter with self-cleaning feature and the original UV/IR blocking bluish filter are replaced by the non-detachable Astronomik clear glass with Anti-Reflective coatings, which is permanently installed in front of the sensor. With the Low Pass Anti-Aliasing Filter removed, the Camera Sensor performs at native maximum sharpness. The focus to infinity with lenses of this Full Spectrum converted Mirrorless camera will work as the regular stock version.
Daylight Infrared photography with a Full Spectrum converted camera
When the digital camera sensor becomes sensitive to ultraviolet and infrared light after the Full Spectrum conversion, specific infrared band pass isolating filters can be used as camera lens filters or camera body clip filters. Infrared filters with different wavelengths are suitable to create artistic expressions with altered color tones or dramatic contrast effects with black and white images produced by deeper infrared filters.
Astrophotography with a Full Spectrum converted camera
The Full Spectrum modification is the best conversion for planetary astrophotography because the usability of infrared isolating filters like the Astronomik ProPlanet 742 IR-pass and 807 IR-pass . The infrared wavelength is significantly less susceptible to poor seeing (atmospheric turbulences) and consequently the resulting images are considerably sharper. Expert planetary imagers process planets photos with images taken with single line infrared filters as a luminance channel.
Regular photography with a Full Spectrum converted camera
For daylight or regular photography an additional UV/IR block or Original White Balance filter is required. The Astronomik L-2 and OWB Clip filters can be used to correct White Balance (Subject to lens and camera model compatibility). Clip filters can be used with Canon EF and RF Lenses (EF-S Lenses are not compatible with clip in filters).
**Out of focus Infrared: An additional UV/IR cut filter is required to capture the pictures in visible light. This filter is a must when imaging with telescopes using refractive elements (refractors, catadioptrics, reducers/flatteners, coma correctors, etc.) If light frames are captured without an UV/IR blocking filter you will get bloated stars, because UV and IR light rays focus on a different distance from the visible light focal plane. A luminance filter, or any narrowband filter will cut off ultraviolet and infrared Wavelengths. With a Ritchey-Chretien Telescope and no flattener/reducer there is no need of an additional UV/IR Blocking filter.
Why buy this magnificent Full Spectrum DSLR Camera?
- Professionally converted on a Neat Work Room with ESD Safe Tools
- Installed Astronomik clear glass with Anti-Reflective coatings and highest quality precision optically polished made
- Sensor Recalibrated with Original Orthogonality for perfect focus with lenses
- 1 Year Warranty*
* Warranty coverage includes manufacturing and conversion defects. Any kind of physical damage, water damage, abuse or misuse of the Full Spectrum converted camera will void the warranty. Since the camera has been disassembled for the modification, this warranty coverage is provided by the Seller (AstroGear), and NOT by Canon U.S.A.
California Residents: Please check Proposition 65 Warning Website about significant exposures to chemicals that cause cancer, birth defects or other reproductive harm.
https://www.p65warnings.ca.gov/
| Lens Mount | Canon RF |
| Camera Format | Full-Frame (1x Crop Factor) |
| Pixels | Actual: 31.7 Megapixel Effective: 30.3 Megapixel |
| Maximum Resolution | 6720 x 4480 |
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
| Sensor Type | CMOS |
| Sensor Size | 36 x 24 mm |
| Image File Format | JPEG, Raw |
| Bit Depth | 14-Bit |
| Image Stabilization | Digital (Video Only) |
| ISO Sensitivity | Auto, 100 to 40000 (Extended: 50 to 102400) |
| Shutter Speed | Electronic Front Curtain Shutter 1/8000 to 30 Seconds Bulb Mode |
| Metering Method | Center-Weighted Average, Evaluative, Partial |
| Exposure Modes | Aperture Priority, Manual, Shutter Priority |
| Exposure Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Metering Range | -3 to 20 EV |
| White Balance | Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten |
| Continuous Shooting | Up to 8 fps at 30.3 MP for up to 47 Frames (Raw) / 100 Frames (JPEG) Up to 3 fps at 30.3 MP for up to 47 Frames (Raw) / 100 Frames (JPEG) Up to 2.2 fps at 30.3 MP for up to 47 Frames (Raw) / 100 Frames (JPEG) |
| Self-Timer | 2/10-Second Delay |
| Recording Modes | MP4/H.264 UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p HD (1280 x 720) at 25p/29.97p/50p/59.94p/100p/119.88p |
| External Recording Modes | 4:2:2 10-Bit UHD 4K (3840 x 2160) |
| Recording Limit | Up to 29 Minutes, 59 Seconds |
| Video Encoding | NTSC/PAL |
| Audio Recording | Built-In Microphone (Stereo) External Microphone Input |
| Audio File Format | AAC, Linear PCM (Stereo) |
| Focus Type | Auto and Manual Focus |
| Focus Mode | Continuous-Servo AF (C), Manual Focus (M), Single-Servo AF (S) |
| Autofocus Points | Phase Detection: 5655 |
| Autofocus Sensitivity | -6 to +18 EV |
| Viewfinder Type | Electronic |
| Viewfinder Size | 0.5" |
| Viewfinder Resolution | 3,690,000 Dot |
| Viewfinder Eye Point | 23 mm |
| Viewfinder Coverage | 100% |
| Viewfinder Magnification | Approx. 0.71x |
| Diopter Adjustment | -4 to +2 |
| Size | 3.15" |
| Resolution | 2,100,000 Dot |
| Display Type | Articulating Touchscreen LCD |
| Built-In Flash | No |
| Flash Modes | Flash On, Slow Sync |
| Flash Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Dedicated Flash System | eTTL |
| External Flash Connection | Hot Shoe |
| Media/Memory Card Slot | Single Slot: SD/SDHC/SDXC (UHS-II) |
| Connectivity | 3.5mm Microphone, HDMI C (Mini), USB Type-C (USB 3.0) |
| Wireless | Wi-Fi Bluetooth |
| GPS | No |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 0 to 85% |
| Battery | 1 x LP-E6N Rechargeable Lithium-Ion, 7.2 VDC, 1865 mAh |
| Dimensions (W x H x D) | 5.3 x 3.9 x 3.3" / 135.8 x 98.3 x 84.4 mm |
| Weight | 1.45 lb / 660 g (Body with Battery and Memory) |
- Used Full Spectrum converted Canon EOS R Body
- Battery Pack LP-E6N
- Battery Charger LC-E6
- Camera Cover R-F-5
To attach the Camera to a Telescope, a T-Ring adapter not included is necessary.
To control the camera with computer software a Type-C to Male USB Cable not included is necessary.
